7H15-1027U9
| Sanden Hasco Series | 7H15 |
| Sanden Hasco Model | 1027U9 |
| Style | Single-directional inclined disc variable displacement compressor |
| Mount Type | 4 Point |
| Ear ID | 4*80 |
| Refrigerant | R134a |
| Displacement | 154.9cm3/r |
| Rotation Direction | CW |
| Oil Qty (cc) | 180 |
| Cylinder Head | die casting |
| Port Angle | axially backward on the rear cover |
| Port Clocking | Rear |
| Head Port Style | sealing plug |
| Rotor Size | 119 |
| Rotor Groove | PV8 |
| Gauge Line to End Groove | 61.5 |
| Coil Voltage | DC24V |
| Connector | AMP42060-1 |
