7H15-1027AA
| Sanden Hasco Series | 7H15 |
| Sanden Hasco Model | 1027AA |
| Style | Single-directional inclined disc variable displacement compressor |
| Mount Type | Ear 8 long |
| Ear ID | 83.3 |
| Refrigerant | R134a |
| Displacement | 154.8cm3/r |
| Rotation Direction | CW |
| Oil Qty (cc) | 180 |
| Cylinder Head | die casting |
| Port Angle | upper part of the axial rear cover |
| Port Clocking | Rear |
| Head Port Style | sealing plug |
| Rotor Size | 119 |
| Rotor Groove | PV5 |
| Gauge Line to End Groove | 46.55 |
| Coil Voltage | DC12V |
| Connector | 141315/141214 |
| Vehicle | Hongyan Genlyon |
