7H15-10273B
| Sanden Hasco Series | 7H15 |
| Sanden Hasco Model | 10273B |
| Style | Single-directional inclined disc variable displacement compressor |
| Mount Type | Ear 8 long |
| Ear ID | 83.3 |
| Refrigerant | R134a |
| Displacement | 154.8cm3/r |
| Rotation Direction | CW |
| Oil Qty (cc) | 150 |
| Cylinder Discuss Closed Head | die casting |
| Port Angle | upper part of the radial rear cover |
| Port Clocking | Rear |
| Head Port Style | sealing plug |
| Rotor Size | 125 |
| Rotor Groove | PV10 |
| Gauge Line to End Groove | 51 |
| Coil Voltage | DC24V |
| Connector | AMP42460-1 |
