10B20-106340
| Sanden Hasco Series | 10B20 |
| Sanden Hasco Model | 106340 |
| 10PA17C DCP12005 | |
| Style | Two-way slant plate |
| Mount Type | 4Point |
| Ear ID | 70 |
| Refrigerant | R134a |
| Displacement | 207.6cm3/r |
| Rotation Direction | CW |
| Oil Qty (cc) | 200 |
| Cylinder Head | die casting |
| Port Angle | backward horizontally |
| Port Clocking | on the intake and exhaustpipe seats |
| Head Port Style | sealing plug |
| Rotor Size | 110 |
| Rotor Groove | PV6 |
| Gauge Line to Middle Groove | 71.5 |
| Coil Voltage | DC12V |
| Connector | AMP174879/AMP171661-1 |
| Vehicle | Fargo Fora, Fiat, Iveco, LDV V80, Maxus LD100, MG V80, Temsa Maxus |
